Description
| FEATURES 1. The new energy-efficient high-speed circular loom, from design to reduce the number of parts, less wearing parts, accessories . 2.Movement part of the non-oil lubrication can make your fabric cleaner. 3Automatic to stop for defects warp & weft can show the place for the out of line;and without the alar system,the workshop can enjoy more peace. 4Can weave with beautiful pattern;With air frozen and air depurated cleanedsystam. 5.High quality and long service life. Electric control for the breaking yarn, Very safe. |
Technical Information
| Model | FH250 |
| Weave dia | 20mm to 250mm |
| Form of machine | Shuttle type |
| Running speed | ~ 95 r/min |
| Efficiency |
~ 26 meters/hour |
| Motor power | 5.5KW or (4KW) |
| warp ends |
478 single ends or double ends . |
| Max diameter | After add some spares and accessories can reach max 250mm dia |
| Shuttle diameter |
840mm |
| Weave pattern | Twill and plain |
| Size | 1850*1850*900mm |
*Power supply for the loom and its controller cabinet, can be manufactured meet to customer's needs, as long as it 3 phase.
