Model	Unit	MH150		MH1000
Verslon		SD	SD PRO	SD
Max shuttle speed	rpm	150	150	150
Number of shuttles		2	2	3
Default weft net single bobbin load	kg	2.3	2.3	3
Default Gross bobbin weight for operator	kg	3.6	3.6	3.7
Default weft total net load	kg	4.6	4.6	9
Default Minimum diameter	mm	20	20	20
Default Maximum diameter "higher on request	mm	160	320	160
Number of warp openings		478	478	411
Number of warp openings with warp entry for double ends		956	956	822
standard weave patterns " other patterns on request		plain/twill	plain/twill	plain/twill
suitable for yarns		polyester polyamide aramide	polyester polyamide aramide	polyester polyamide aramide
Default rail gap	mm	1.75	1.75	1.8
optional rail gap	mm	2.6	2.6	/

Default motor size	kw	7.5	7.5	7.5
optional motor	kw	5.5	5.5	/
default voltage	v
default frequency	hz	50	50	50
default shuttle direction		clockwise	clockwise	clockwise
optional shuttle direction		counter- clockwise	counter- clockwise	/
default picks control		electrical	electrical	electrical
optional picks control		mechanical	mechanical	mechanical
air cooling recommended		YES	YES	YES
automatic weft break stop		included	included	included
automatic weft bobbin empty stop		included	included	included
automatic low tension stop		included	included	included
automatic high tension stop		optional	optional	optional

noise level	dB	92-95	92-95	92-95
Floor space diameter required	mm	1980	1980	1750
footprint of base	mm	1400	1400	1400
height	mm	997	997	1050
default weight approximately "floor take off not included	kg	1500	1350	1350
other loom modifications on request
